20+40+20ft Multi-Expandable Home

20+40+20ft Multi-Expandable Home

Buy Now, Pay Later with Learn more
This 80ft home combines two 20ft & one 40ft Expander Home, seamlessly connected by prefabricated link modules for a spacious, modern layout. With high ceilings, premium finishes, and a durable, weather-resistant design, it offers a versatile and cost-effective living solution.

Description

This 80ft expandable container home is constructed from a steel frame treated with epoxy and acrylic paint for long-lasting resilience against corrosion. It features a pitched roof and full glass entrance, adding a touch of modern elegance while welcoming natural light into the living space.

Key Features:

  • Pitched Roof - The pitched roof is manufactured from a galvanized steel plate with fiberglass reinforcement and features a 10-degree angle, enhancing the building’s aesthetics. The design ensures efficient drainage, with roof eaves extending 180mm beyond the walls to protect the exterior from rain, snow, and sunlight.

  • Link Module - This unique design consists of one 40ft Expandable Home with two 20ft Expandable Homes at either end of the building connected via two steel link modules.

  • Interior Floor - The interior boasts 18mm sub-flooring with a 2mm PVC top layer, making it resistant to moisture, stains, scratches, and wear. The 2.4m floor-to-ceiling height complies with the National Construction Code within Australia.

  • Kitchen - Designed in the style of a butler’s pantry, this space enhances functionality and organization within the kitchen. It features provisional space for a dishwasher, fridge and oven, making meal preparation and clean-up effortless. Overhead cabinetry provides ample storage for kitchen essentials, while dedicated shelving cabinetry keeps pantry items neatly arranged. This layout ensures a clutter-free main kitchen, offering both practicality and a modern, streamlined aesthetic.

  • Bathrooms - The container home features two bathrooms, strategically positioned at either end of the connected building for convenience and privacy. The bathrooms consist of a full-width shower with a shower rail and a luxurious rainmaker shower head. A soft-close toilet lid adds sophistication, while a stainless-steel tap and vanity with a mirror complete the elegant and functional space.
  • Walk-In-Robes - The building includes three built-in walk-in robes, each located in the bedrooms for convenient and efficient storage.
  • Bedrooms - The building consists of the 3 spacious bedrooms.
  • Dedicated Laundry - The building includes a designated laundry room, providing a practical and efficient space for washing and drying, separate from the main living areas.

Please Note:

Furniture, robes, patio, and decking are not supplied with the building.

This building must be elevated at least 500mm from the ground to allow access for plumbing underneath.



Product Improvements:

Ongoing improvements may result in slight variations between the images on our website and the actual product.

Dimensions

Weight

Approx | 22,500kg

Ask a question

View full details

Our Features

Sliding Windows With Flyscreens

Sliding Windows With Flyscreens

Vinyl Timber Look Flooring

Vinyl Timber Look Flooring

Stone Bench Top

Stone Bench Top

Under Bench Cabinets

Under Bench Cabinets

Overhead Cabinets

Overhead Cabinets

Sink and Mixer

Sink and Mixer

Glass sliding door

Glass sliding door

Cornice And Skirting

Cornice And Skirting

Switchboard

Switchboard

Shaving Cabinet

Shaving Cabinet

Bathroom Vanity

Bathroom Vanity

PowerPoints

PowerPoints

Plumbing Connections

Plumbing Connections

Lockable Bedroom Doors

Lockable Bedroom Doors

Toilet

Toilet

Exterior Cladding

Exterior Cladding

Prewired Mains Power

Prewired Mains Power

Galvanised Steel Frame

Galvanised Steel Frame

LED Downlights

LED Downlights

Shower

Shower

Floor & Electrical Plans

Specifications

General

Entry Door Sliding glass and lockable entry door
Windows Aluminium double-glazed windows
Electrical Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame Galvanised steel frame, epoxy treated & acrylic painted
Roof Due to the flat 2400mm floor-to-ceiling height, the pitched roof (supplied) must be installed on the Expander to help with water run off. Additionally it contributes to the thermal insulation values of the Expander
Walls Interior walls are 50mm EPS with off white finish
Flooring Water & insect resistant magnesium concrete composite
Lighting LED oyster lights supplied
Council Compliance Please note that the Expander Homes do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.

External Walls

With Cladding 60mm EPS Panel Walls & 15mm Cladding
No Cladding 75mm EPS Panel Walls

Windows

Frames Aluminium framed windows
Glass Double-glazed windows
Thickness 5mm glass

Doors

Entry Sliding glass and lockable aluminium entry door
Bathroom Privacy glass bathroom door

General

Entry Door Sliding glass and lockable entry door
Windows Aluminium double-glazed windows
Electrical Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame Galvanised steel frame, epoxy treated & acrylic painted
Roof Due to the flat 2400mm floor-to-ceiling height, the pitched roof (supplied) must be installed on the Expander to help with water run off. Additionally it contributes to the thermal insulation values of the Expander
Walls Interior walls are 50mm EPS with off white finish
Flooring Water & insect resistant magnesium concrete composite
Lighting LED oyster lights supplied
Council Compliance Please note that the Expander Homes do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.

Frame

Sub-Floor Steel Chassis 150x100 Rectangular Hollow Section (RHS)
Steel Post 150x150 Square Hollow Section (SHS)
Steel Floor Bearer 70x50 Rectangular Hollow Section (RHS)
Steel Floor Joist 50x30 Rectangular Hollow Section (RHS)
Castings Corner castings on each corner
Coating Epoxy coated and painted in gloss

Bathroom

Overview The bathroom is fitted out and complete
Shower Full room width shower on acrylic shower base
Toilet S-trap toilet with soft closing lid
Shower Head Rain maker shower head with hand piece, adjustable shower rail
Vanity & Sink Vanity with porcelain sink, chrome flick mixers
Walls Marble look wall PVC wall lining
Tiles Grey floor tiles

Installation

Instructions Unfolding instructions and video provided for the Expander
DIY Express Portable Expanders are customer DIY installations
Footing Plans Footing Plans supplied by Express Portables
Electrical & Plumbing The customer must engage a licenced Plumber and Electrician to carry out any plumbing and electrical work

Transport

Crane Truck self unloads with own crane. Reach is usually 2m-6m from side of the truck’s tray from where it can park, set up and safely unload
Tilt-Tray The truck carefully slide unloads the building to the rear of the truck. Manoeuvrability and access around the site is essential, the truck requires 10-15m in a straight line to slide unload and drive away
Rigid Truck/Semi Trailer Customer is required to organise a forklift unload or crane unload

Walls

Interior Walls 50mm EPS Panel with an off white finish

New Features

Design Unique design only available through Express Portables
Internal Ceiling Height 2400mm floor to ceiling height
Roof Pitched Roof
Side Access Large sliding doors leading on to deck
Laundry Dedicated laundry room

External Walls

With Cladding 60mm EPS Panel Walls & 15mm Cladding
No Cladding 75mm EPS Panel Walls

Windows

Frames Aluminium framed windows
Glass Double-glazed windows
Thickness 5mm glass

Doors

Entry Sliding glass and lockable aluminium entry door
Bathroom Privacy glass bathroom door

Roof

Steel Plate 3mm steel plate over the main body
Exterior Panels 75mm EPS panels on outside folding roof panels

Flooring

Sub-Floor Magnesium subfloor concrete composite – water, rot and insect resistant
Top Layer 2mm vinyl timber pattern - Grey or Brown
Floor Trims Aluminium colour-matched floor trims were provided to cover folding/hinge join. Powercoated internal trims

Kitchen

Shape Island Kitchen
Cabinetry Prebuilt kitchen cabinets packaged in a protective film ready for installation & overhead cabinets with soft closing hinges
Sink Double bowl stainless sink with flick mixer
Benchtop Engineered stone with zero silica (test certificate supplied)
Provisional Space Provisional space for dishwasher, freestanding cooker, rangehood, fridge.

Electrical

PowerPoints All electrical points are pre-wired inside walls. 15amp air conditioner high wall PowerPoint included in living room and all bedrooms
Lighting All lights and switches are pre-wired inside walls. Fit off of points required after opening and installing the building
Smoke Alarm Smoke alarm hardwired back to switchboard per habitable room, customer to supply/install smoke alarm
Aerial Point Aerial point provided for TV (cable connection on rear exterior wall with plumbing)
Mains Site mains electrical supply connected by hardwire, located at rear of Expander

Plumbing

Overview Bathroom is pre-plumbed
Laundry Tub Laundry tub is pre-plumbed
Water & Waste Water and waste lines provided to kitchen sink for easy connection after opening the building

Council Compliance

Council Approval Please note that the Expander Homes do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.
Certificates Structural engineering and plumbing certificates are not provided with the purchase

Laundry

Overview Laundry tub is connected to plumbing with waste and water penetrating through the floor.

Pitched Roof

Overview Due to the flat 2400mm floor to ceiling height the pitched roof (supplied) must be installed on the Expander to help prevent want run off. Additionally it contributes to the thermal insulation values of the Expander
Trusses Steel trusses, roof sheets and fixings supplied. Truss layout provided
Decking Deck supplied as prebuilt modular (Optional Extra)
Patio Patio supplied as a flatpack kit (Optional Extra)

80ft Multi Expander
