Specifications
General Overview
Entry Door
50mm EPS entry door with steel sheet covering
Windows
Double-glazed awning window
Electrical
Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame
Galvanised steel frame, epoxy treated & acrylic painted
Roof
Glass-wool insulation, galvanised & painted steel
Walls
50mm EPS panel
Floor
Water & insect resistant magnesium concrete composite
Lighting
LED ceiling light
Certificates
Structural engineering and plumbing certificates are not provided with the purchase
Windows
Frames
Aluminium framed windows
Type
Double-glazed awning window
Flyscreens
Retractable flyscreen installed
Door
Shower
Frosted glass sliding shower door and fixed glass panel
Entry
50mm EPS entry door with steel sheet covering
General Overview
Entry Door
50mm EPS entry door with steel sheet covering
Windows
Double-glazed awning window
Electrical
Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame
Galvanised steel frame, epoxy treated & acrylic painted
Roof
Glass-wool insulation, galvanised & painted steel
Walls
50mm EPS panel
Floor
Water & insect resistant magnesium concrete composite
Lighting
LED ceiling light
Certificates
Structural engineering and plumbing certificates are not provided with the purchase
Bathroom
Accessories
Commercial toilet roll holder, rain shower head, toilet brush
Shower
Chrome shower set including rain shower and hand piece
Shower
Frosted glass sliding shower door and fixed glass panel
Toilet
Modern toilet and soft close seat
Vanity
Porcelain vanity with chrome mixer tap
Cabinets
Mirror storage unit over vanity
Exhaust Fan
Prewired and installed
Wall
50mm EPS panels
Installation
Instructions
Instructions provided
DIY
Bathrooms are a customer DIY installation, Express Portables will supply only
Footing Plans
Footing Plans supplied by Express Portables. Level site prepared and/or footings prepared by customer
Electrical & Plumbing
The customer must engage a licenced Plumber and Electrician to carry out any plumbing and electrical work
Transport
Crane
Truck self unloads with own crane. Reach is usually 2m-6m from side of the truck’s tray from where it can park, set up and safely unload
Tilt- Tray
The truck carefully slide unloads the building to the rear of the truck. Manoeuvrability and access around the site is essential, the truck requires 10-15m in a straight line to slide unload and drive away
Rigid Truck/Semi Trailer
Customer is required to organise a forklift unload or crane unload
Internal Walls
Interior Walls
50mm EPS wall insulation - EPS sandwich panels
Windows
Frames
Aluminium framed windows
Type
Double-glazed awning window
Flyscreens
Retractable flyscreen installed
Door
Shower
Frosted glass sliding shower door and fixed glass panel
Entry
50mm EPS entry door with steel sheet covering
Roof
Interior Roof
Glass-wool insulation & marble look ceiling panel
Exterior Roof
Exterior roof is 3mm steel sheet finished in epoxy paint
Flooring
Sub-Floor
18mm Magnesium subfloor concrete composite – water, rot and insect resistant.
Top Layer
2mm vinyl timber pattern
Features
Lifting Lugs
Roof mount lugs for crane lifting
Forklift Pockets
Forklift pockets for lifting
Electrical
Power
Prewired to switchboard
Lighting
LED downlights pre-installed and wired
Plumbing
Hot & Cold
Hot and cold brass threaded fittings are mounted through the wall ready for connection onsite.
Waste
Shower and vanity wastes penetrate through the rear wall. No access is required under the building
Sewer
Sewer connection for the toilet is through the side wall
