Single Toilet

Single Toilet

Regular price $4,250.00
Regular price
$4,250.00 (Incl. GST)
Sale price $4,250.00
(Incl. GST) Sale Sold out
Buy Now, Pay Later with Learn more
This portable single-toilet block is made from a structural steel frame and 50mm EPS panel walls. Can be connected to mains or can be left as a stand-alone block with a waste tank system.

Description

The portable single toilet block is the ultimate solution for all your outdoor bathroom needs. It can be installed as a permanent or temporary solution. The simple design can be connected to the existing property with mains power, sewerage and water.

Designed for all your outdoor bathroom needs. The structural steel frame ensures durability, while 50mm insulated EPS panels provide a comfortable and climate-controlled interior. There is also a built-in exhaust fan ensuring effective ventilation, swiftly removing odours and maintaining a pleasant environment. We also offer a double toilet block which may be a more efficient and effective option.

Perfect for events, construction sites, or any temporary setting.


Dimensions

Length: 1.3m | Width: 1.1m | Height: 2.36m

Weight

304kg

Ask a question

View full details

Key Features

Steel Frame

Featuring a steel frame ensuring structural integrity and stability. Engineered to withstand harsh weather conditions and the rigors of transportation, the steel frame provides a secure foundation for the entire structure.

Exhaust Fan

The exhaust fan effectively removes odors and ensures proper ventilation within the confined space by continuously circulating air.

Lifting Lugs

Equipped with lifting lugs on its top, allowing for straightforward lifting and transportation. These robust lugs serve as secure attachment points for cranes or lifting equipment during relocation or installation.

Tie Down Cleats

Robust fixtures designed to secure the restroom firmly in place during transportation or stationary use. These cleats allow for reliable anchoring, ensuring stability and preventing movement.

Specifications

General Overview

Entry Door 50mm EPS panel
Windows Double-glazed awning window
Electrical AS/NZ electrical cable, power points & switchboard (Qualified Electrician Required)
Frame Galvanised steel frame, epoxy treated & acrylic painted
Roof Glass-wool insulation, galvanised & painted steel
Walls 50mm EPS panel walls
Floor Water & insect resistant magnesium concrete composite
Lighting LED oyster lights supplied

Windows

Frames Aluminium framed windows
Type Double-glazed windows
Thickness 5mm glass

Doors

Shower Privacy glass bathroom door
Entry 50mm EPS

General Overview

Entry Door 50mm EPS panel
Windows Double-glazed awning window
Electrical AS/NZ electrical cable, power points & switchboard (Qualified Electrician Required)
Frame Galvanised steel frame, epoxy treated & acrylic painted
Roof Glass-wool insulation, galvanised & painted steel
Walls 50mm EPS panel walls
Floor Water & insect resistant magnesium concrete composite
Lighting LED oyster lights supplied

Bathroom

Accessories Paper roll holder, rain shower head, toilet brush, soap holder
Shower Corner shower & acrylic base
Toilet Modern toilet and soft close seat
Vanity Porcelain vanity with chrome mixer tap
Compliance Fixtures and fittings WELS Watermark AS/NZS 6400:2016 compliant
Wall 50mm EPS Panel with a Marble like PVC finish

Installation

Instructions Instructions provided
DIY Bathrooms are a customer DIY installation, Express Portables will supply only
Footing Plans Footing Plans supplied by Express Portables. Level site prepared and/or footings prepared by customer
Electrical & Plumbing The customer must engage a licenced Plumber and Electrician to carry out any plumbing and electrical work

Transport

Crane Truck self unloads with own crane. Reach is usually 2m-6m from side of the truck’s tray from where it can park, set up and safely unload
Tilt-Tray The truck carefully slide unloads the building to the rear of the truck. Manoeuvrability and access around the site is essential, the truck requires 10-15m in a straight line to slide unload and drive away
Rigid Truck/Semi Trailer Customer is required to organise a forklift unload or crane unload

Internal Wall

Interior Walls 50mm EPS Panel with a Marble like PVC finish

Windows

Frames Aluminium framed windows
Type Double-glazed windows
Thickness 5mm glass

Doors

Shower Privacy glass bathroom door
Entry 50mm EPS

Roof

Interior Roof 50mm EPS panels
Exterior Roof Exterior roof is 3mm steel sheet finished in epoxy dark grey paint

Flooring

Sub-Floor Magnesium subfloor concrete composite – water, rot and insect resistant
Top Layer 2mm vinyl timber pattern
Skirting PVC cornice and skirting

Features

Tie Down Cleats Allow for reliable anchoring
Vanity Porcelain vanity with chrome mixer tap
Lifting Lugs Roof mount lugs for crane lifting
Forklift Pockets Forklift pockets for transport

Electrical

Power Mains electrical cable terminated on rear wall ready for connection to site
Lighting LED downlights pre-installed and wired

Plumbing

Hot & Cold Hot and cold water water lines pre-installed, connections through wall
Waste 42mm waste pre-plumbed (vanity, floor waste & shower), connection through wall
Sewer Sewer connection through rear wall
