Specifications
General
Entry Door
Double glazed entry door with keyed lock
Windows
Caravan style windows with blinds and flyscreen
Electrical
Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame
Structural steel chassis painted in black epoxy enamel
Roof & Walls
White Fluorocarbon exterior panel | 50mm PU Foam Insulation
Floor
2mm vinyl timber pattern - Grey or Brown
Lighting
LED oyster lights supplied
Council Compliance
Please note that the Spacee products do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.
Windows
Frames
Aluminium framed windows with flyscreens
Type
Double-glazed awning window
Thickness
5mm Glass
Doors
Entry
Double glazed entry door with keyed lock. The door is 840mm wide.
General
Entry Door
Double glazed entry door with keyed lock
Windows
Caravan style windows with blinds and flyscreen
Electrical
Australian Standard electrical products are installed and/or supplied. The building is sold in accordance with the Electrical AS3000 standards and electrical items carry the RCM logo which meets the Australian electrical safety regulations. The customer's qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Frame
Structural steel chassis painted in black epoxy enamel
Roof & Walls
White Fluorocarbon exterior panel | 50mm PU Foam Insulation
Floor
2mm vinyl timber pattern - Grey or Brown
Lighting
LED oyster lights supplied
Council Compliance
Please note that the Spacee products do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.
Installation
Instructions
Instructions provided
DIY
The 3m Pod - Open Plan is a customer DIY installation, Express Portables will supply only
Electrical & Plumbing
The customer must engage a licenced Plumber and Electrician to carry out any plumbing and electrical work
Transport
Crane
Truck self unloads with own crane. Reach is usually 2m-6m from side of the truck’s tray from where it can park, set up and safely unload
Tilt-Tray
The truck carefully slide unloads the building to the rear of the truck. Manoeuvrability and access around the site is essential, the truck requires 10-15m in a straight line to slide unload and drive away
Rigid/Semi-Trailer
Customer is required to organise a forklift unload or crane unload
Windows
Frames
Aluminium framed windows with flyscreens
Type
Double-glazed awning window
Thickness
5mm Glass
Doors
Entry
Double glazed entry door with keyed lock. The door is 840mm wide.
Flooring
Sub-Floor
18mm Magnesium subfloor concrete composite – water, rot and insect resistant
Top Layer
2mm vinyl timber pattern
Features
Interior switchboard
Internal switchboard prewired
Electrical
Power
A qualified electrician is to complete the hardwired electrical supply to the building, complete electrical fit off (if required) and test the installation according to AS3000.
Lighting
LED downlights pre-installed and wired
Power Points
Multiple power points and a 15amp power point installed for an air conditioning unit
Council Compliance
Council Approval
Please note that the Spacee products do not fall under the Class 1a building category that conforms with the regulations stipulated by the Building Code of Australia (BCA). If any of our Products are purchased together with our Trailers, they are considered as a Caravan (movable dwelling) and can be conveniently installed in numerous Councils without requiring approval from the council.
Certificates
Structural engineering and plumbing certificates are not provided with the purchase
